ECLISSE Push & Pull System

Description

• Studied for ECLISSE track (100 Kg capacity);
• Suitable for both wooden and glass door panels;
• Minimum internal passage 54 mm;
• For single door, applicable on models with passage sizes from 600 to 1200 mm;
• For double door, applicable on models with passage sizes from 600+600 to 1200+1200 mm;
• For double door, one ECLISSE Push&Pull per each door panel is required;
• Maximum door panel weight 50 kg;
• Minimum activation force 30 N;
• It can be installed together with ECLISSE BIAS;
• It cannot be installed with ECLISSE BIAS DS and Double door coordination;
• Thanks to the extractable track, it can be retrofitted;
• The underneath of the door panel has to be milled for its entire length (a through-milling is required).

Push&Pull C (Suitable for models from the Classic Collection, except for ECLISSE Telescopic and ECLISSE Circular)

Push&Pull S (Suitable for all sliding Syntesis models)
